Scanner Equipment- BioVisual WP 3000

   BioVisual

      WP 3000

BioVisual WP 3000 Imaging Modes

  • Soft Tissue Imaging
  • Color Doppler
  • Pulsed Wave Doppler
  • Power Doppler
  • Real Time Zoom
  • Vertical Scrolling
  • Dynamic and Frozen Zoom

BioVisual WP 3000 Features

1024 x 768 15" Flat Panel Active Matrix Screen - Protective anti-glare, anti- reflective surface - Adjustable Brightness

IMAGING MODES:

B-Mode, Fundamental and Harmonic Imaging

M-Mode

Power Doppler

Color Doppler

Pulsed Wave Spectral Doppler

Duplex Doppler (Simultaneous, Real-Time 2D, and /Spectral Doppler display)

Triplex Display= (Simultaneous, real-time 2-D, Color Doppler and Spectral Doppler display)

TRANSDUCERS-

 12L5 Linear Array                       7L3 Linear Array

 4C2 Curvilinear Array                   4V2 Phased Array

 12HL7 "Hocky Stick"Linear Array    10V5 Phased Array

 8B4S Biplane Curvilinear and Linear Array

 8EC4 Tightly Curved Array            8MC4 Curvilinear Array

Digital Image Acquisition, Storage & Management

Internal hard drive for image and data storage

Integrated CD-RW Drive

Internal Storage for more than 50,000 images

Storage of Dynamic Clips and Static Images

User-selectable formats for digital images and dynamic clips

Lossless native format- AVI, BMP, TiFF, and Jpeg

DICOM 3.0 Format

Pres set - APPLICATIONS

Musculoskeletal (podiatry)   -   Breast

Small Parts  -  General  -  Small Parts

Wound-Mapping® / HydroStep® Settings

Vascular, Cardiac, Abdominal, OB-GYN, Prostate, Thyroid, Renal & more (probe dependent)

Measurements - 2D Distance - 2D Ellipse - 2D Trace - 2D Hip Joint

                         3D Volume (3 distance) 3D Volume (1 distance)

                         3D Volume (Distance + Ellipse)

Measurement & Calculations in @D, M-Mode, Color Doppler, PW & CW Spectral Modes

CardioVascular measurements & Calculations

Vascular Reporting.

Advanced CardioVascular Option: ECG Trace, Continuous Wave Spectral Doppler & reporting

 SOFTWARE Options:

PictZar-CDM

Voice Activation Option

Surface Rendering 3D Imaging Option



BATTERY OR AC POWER
